This technical guide provides a comprehensive overview of CNC transverse cutting (CTL) production lines, developed and manufactured by Zibo Ruilin Machinery Co., Ltd. As a specialized supplier in metal processing machinery with mature R&D and manufacturing capabilities, we focus on delivering high-precision, efficient solutions for global clients. These lines are designed to address key industry pain points including sheet warping, surface scratches, and inefficient changeovers, strictly adhering to international standards such as ISO and ASTM. With core innovations in servo-driven control and modular design, our equipment serves over 500 clients across sectors like 3C electronics, new energy vehicle (NEV) battery manufacturing, and automotive parts production, ensuring reliable performance and measurable cost savings .
CNC transverse cutting production lines are CNC-controlled industrial equipment that uncoils, levels, and cuts metal coils into dimensionally precise flat sheets, based on PLC servo synchronous control technology. They enable high-efficiency, consistent processing of various metal materials, serving as a critical component in metal fabrication workflows . Our product range includes two mainstream series to meet diverse needs: 1×1250MM CTL, a high-precision series for ultra-thin sheets (0.2-2.0mm) ideal for 3C and NEV battery applications with non-destructive processing features; and 3×1650MM CTL, a multi-material series for medium-thick sheets supporting mixed production of high-strength steel and automotive body steels . Our design centers on high precision, energy efficiency, and quick changeover to adapt to diverse industrial scenarios .
The core working principle relies on PLC servo synchronous control, creating a seamless three-step workflow: first, tension-controlled uncoiling and feeding to prevent material deformation; second, multi-roll leveling to eliminate internal stress and ensure sheet flatness; third, servo-driven transverse cutting for precise length tolerance . Key innovative modules include the Servo Drive Module, which delivers ±0.05mm cutting precision and boosts production efficiency by 40% compared to traditional equipment, and the Modular Changeover System, which reduces changeover time from 2 hours to 30 minutes via standardized interfaces . Unlike traditional lines with manual adjustments and low precision, our solutions eliminate sheet warping and surface scratches, ensuring consistent product quality .
All parameters are tested per international standards, with core specifications including:
Material Compatibility: 0.1-20mm thickness, 30-2200mm width, covering high-strength steel, titanium alloys, and ultra-thin aluminum foils
Cutting Precision: ±0.05mm length tolerance, ≤0.03mm/m flatness
Production Speed: Up to 260m/min for slitting lines
Energy Efficiency: 15% lower consumption than industry average, saving ¥300,000 annually per line
Customized specifications are available based on client requirements .
1. High Precision & Efficiency: Servo-driven systems achieve ±0.05mm precision and 40% higher efficiency, reducing material scrap and increasing production output . 2. Energy Efficiency: Permanent magnet synchronous motors and energy recovery systems cut energy costs by ¥300,000 per line annually . 3. Quick Changeover: Modular design reduces changeover time to 30 minutes, perfectly adapting to multi-variety, small-batch production .
Q: What is the cutting precision of your CNC transverse cutting lines?
A: Our servo-driven lines achieve ±0.05mm length tolerance and ≤0.03mm/m flatness, far exceeding industry benchmarks .
Q: Can you provide customized solutions for non-standard requirements?
A: Yes, we offer tailored lines based on material thickness, width, and output needs, supporting full non-standard customization .
Q: How do you ensure equipment quality before shipping?
A: We conduct a 5-tier QC process including loaded testing and continuous operation tests, and provide testing videos or third-party inspection options for verification .
